-22-
8.6. Display
Menu Functions Description
Bright.cntrl
ColorSh.Cntrl
Day
Night
Color scheme Manual choice of the colour scheme (Day /Night)
Refresh Speed
Brightn./Day Brightness level during the day - select manual or auto switch in the "Bright.cntrl" menu
Brightn./Night Brightness level at night - select manual or auto switch in the "Bright.cntrl" menu
Digital
Color Setting Setting the color scheme of the "Displays Parameters" type 1, 2, 4.
Odd Line Text Font color in odd lines (or parameter in odd position) selection.
Even Line BkGnd Background color in even lines selection.
Even Line Text Font color in even lines (or parameter in even position) selection.
Even Line BkGnd Background color in even lines selection.
Frame Frame colour for displays Type 2 and Type 4 selection.
Active Menu Text Active menu or parameter font color selection.
Active Menu BkGnd Active menu or parameter background color selection.
Hot Menu Text Selection of the ordinal number font color in the Hot Menu
Bott.Panel Selection of the bottom panel color of the Display type 1
x4 type Color selection for the "User's Display" type 2
x6,x9 type Color selection for the "User's Display" type 3, 4
Params setting x4 Setting up the multi-display of the "Parameters" display type 2; enabling/disabling the Displays viewing
Params setting x9 Setting up the multi-display of the "Parameters" display type 4; enabling/disabling the Displays viewing
Params setting x1
Params setting Aver Turning on/off the "Average Display" viewing
Params setting x6 Turning on/off the "User's Display" type 3 viewing, setting up the multi-display function
ProgressBar
Graphic
Color Setting Setting the color scheme of the "Displays Parameters" type 6
Axes Text Line color of horizontal and vertical axes selection
Axes BkGnd Background color of displays the "Parameters" type 6 selection
Chart 1 Color Chart 1 (top) color selection
Chart 2 Color Chart 2 (bottom) color selection
Titles BkGnd Selection of the background color for chart titles.
Params setting Selecting the parameters to be displayed on the charts; enabling/disabling the Displays viewing
Chart range
Chart period
Countdown Turning on the "Countdown" function, for details go to page 15
Arrow
Colors Setting Setting the color scheme of the "Displays Parameters" type 5
Main BkGnd Selecting the background color of the displays "Parameters" type 5
Titles Text Color selection of the title text under the faces
Titles BkGnd Titles background selection
Left Dial Color Left dial color selection
Right Dial Color Right dial color selection
Left Scale Text Left face numbers color selection
Right Scale Text Right face numbers color selection
Left Arrow Left face arrows color selection
Right Arrow Right face arrows color selection
F/100 24/80 Color selection of the face when the instantaneous fuel consumption rate exceeds 24 liters per 100 km.
Params setting Selection of parameters to be displayed as faces; enabling/disabling the Displays viewing
Logo Disable the screensaver when the trip computer is switched on.
Display Sign.
Add.panel Selection of parameters and warnings to be displayed on the sidebar in the "User's Displays".
MomFuelCns
Brightness setting:
Time - adjusts the brightness automatically based on time of day.
Man. - manual brightness adjustment. To change the brightness press and hold the "F" button (when in the "Display
Parameters and Average").
Color scheme setting:
Time - adjusting the color scheme automatically based on time of day.
Man. - manual color adjustment. For manual change of the color scheme.
"Day" mode setting.
Only with the "Bright.cntrl - Time" or "ColorSh.Cntrl - Time"
"Night" mode setting.
Only with the "Bright.cntrl - Time" or "ColorSh.Cntrl - Time"
Color palette
(C. 1...16 R G B)
RGB color palette setting:
R - red color, G - green color, B - blue color.
Setting the screen refresh rate from 1 to 4 times per sec. Note that screen refresh frequency depends on the speed the trip
computer comunication via protocol, not on the settings chosen.
Turning on/off parameters viewing in the "User's Display" type 1
Selection of parameters displaying on the additional panel at the bottom of the screen.
The value of the progress bar scale in the Display type 1 and 3.
Max - the maximum value of the scale is equal to the maximum possible value of the parameter.
Bounds — the maximum value of the scale is equal to the set limit of the parameter warning (Settings Display - Limits).
Aut - recalculation of the max and min values of the parameter depending on its current value.
Max - chart building is always carried out within the maximum possible limits of the parameter.
Setting the time (0.25...99 seconds) after which the parameter chart will be rebuilt.
The chart period should be the same for the parameters displayed on the display at the same time.
Dynamics
Smooth / Data
Smooth - smooth movement of the arrows occurs with a slight delay when changing the parameter.
Data - arrows show the current value of the parameter after a sharp change there may be jerks.
Disable showing the names of the displays: when pressing the buttons only the parameters of the selected display will be
seen, the display name is neither seen nor voiced.
Selection of fuel consumption image: "liters per 100 km" or "km per 1 liter". The change affects only the digital image of the
parameter (in the displays "Parameters" and "Averages"), for arrow and graphical image, "liters per 100 km" is always
shown.
