Murphy Selectronic TTD Series User Manual

Section 50 00-02-0329
01-09-07 - 29 -
Sensor Types
0
Class A
1
Class B1
2
Class B2
3
Class C
4
Class A Alarm
5
Class B1 Alarm
6
Class B2 Alarm
7
Class C Alarm
8
ESD
9
Ignore (Disabled)
10
Special Lockout*
11
Remote Reset**
12
Remote Lockout**
13
No-flow**
* Special Lockout is a fixed 5-minute timer. This timer starts at the same time as the B1 and B2
timers. While timing, the channel assigned this "type" is locked out. Unlike the B1 and B2
timers, this timer cannot be reset or zeroed while the unit is running. The timer is reset only
after shutdown or normal stop.
Up to 48 dry contact sensor inputs or Murphy device transistor outputs can be connected to
the TTD via a terminal block with 48 pair, screw type, each with a jumper for N.O. (Normally
Open) or N.C. (Normally Closed) configuration.
** Settings represented as numbers for placeholders only. These values can only set through
other menu options in the TTD.
