Section 50 00-02-0329
01-09-07 - 49 -
Dimensions
WARNING! Perform the mounting operation with power source off.
The TTD head was designed to be mounted within a weatherproof
enclosure. It is intended for mounting in a flat panel. A square
mounting hole of 5-1/2 in. (140 mm) and 4 mounting screw holes are
needed. Insert the module from the front side of the panel and
secure the 4 mounting screws and nuts through the bezel.
