2
| CONTENTS
1. Concerning this manual 3
2. Safety Information 3
2.1 Designated Use 3
2.2 Target Groups 3
2.3 Regulations 3
2.3.1 General Information 3
2.4 License Disclaimer 3
2.5 Example of Symbols 4
2.5.1 Use of Attention Signs 4
2.5.2 Use of Danger Signs 4
3. Installation Information 4
3.1 XtremeDB Installation 4
4. Module Overview 6
4.1ConguringtheBaudRate 7
4.2ConguringtheNodeID 8
4.3PoweringtheModule 9
4.4 LEDs 10
4.4.1 LED Status 11
4.5 Circuit Protection 12
5. Module Conguration 13
5.1CongurationSteps 13
5.2OutputConguration 16
5.2.1PoweringtheOutputs 16
5.2.2OutputLayout 17
5.2.3ConguringOutputs 18
5.2.4 Output Operation 20
5.3InputConguration 23
5.3.1PoweringtheInputs 23
5.3.2 Input Layout 24
5.3.3ConguringInputs 25
5.3.4InputAOperation 28
5.3.5InputBOperation 28
5.3.6Frequency 30
5.3.7Counter/EncoderInputOperation 31
5.3.8EncoderOperation 34
5.4StatusMessages 35
5.4.1ModuleStatus 35
5.5DataSheet 37
5.5.1PortConguration 37
5.5.2TechnicalData 39
6. Message Structure 40
7. PGNs Used 52
8. Firmware Updates 53
*Thisusermanualappliestormwarerevision34044-561-0211orhigher
