A Murrelektronik Company
A Murrelektronik Company
25
5.3.3 CONFIGURING INPUTS
Input Mode
Inputscanbeconguredin2ways,globally,orindividually.BothcongurationstypesusethesamePGN.PGN61408isusedfor
multiplemessagesbyuseofadierentvalueputintothe“Command”byteofthePGN.Thisvalueisusedasanindexorpointerasto
wheretheinformationgoesinthemodule.
A. Global Input Conguration
(Onlyusedifyouwantalltheinputstobeconguredthesame.Onlyworksfordigitalconguration.)
Conguringalloftheinputsisdonethroughthe“MODE2”byteinPGN61408.TheJ1939messagestructure,
Name Data Type Byte Bits Description
Command Byte 1 Commandforindexpointer(whichmessageyou’resending)
CtrlModeReset
2 bit
2
1,2 EnablesControllerModeOutputReset
EnableStatus1Msg 3,4 Enablestheconstanttransmissionofstatusmessage1
EnableStatus2Msg 5,6 Enablestheconstanttransmissionofstatusmessage2
EnableAmpMsg 7,8 Enablestheconstanttransmissionofamperagemessages
Enable24VDC
3
1,2 Enablesthelowandovervoltagefaultlimitsfor24VDCsystem
SaveConguration 3,4
Savesthecongurationtothemodule(otherwisechangesonlyvaliduntilapowercycleoccurs),
setto1towritecongurationtomodule
Analograwvalue 5,6 Internal Use Only
7,8
4
1,2
3,4
5,6
7,8
FREQ1 Word
5
Setstheglobalcongurationofthefrequencyforallchannels.
LowByteFREQ1:Valueindecimal(40-1100Hz).Example:0xC8h=200d=200Hz.
6 HighByteFREQ1
MODE1 4 Bit 7
SetsthecongurationofALLtheoutputs,overidesCommand53and54.(0=Mode 1 Not Used, 1=ON/
OFF, 2=Data 0-4000, 3= Percent 0-100.0%(0-1000),4= Amps (0-4000ma) Can't be used in this mode
MODE2 4 Bit 7
Setsthecongurationoftheinputs.(0=Mode2NotUsed,1=DigitalPositive,2=DigitalGround)
No analog
ID1 Byte 8 UserdenedbyteforcongurationID,thiswillbetransimittedintheSTATmessage.
PGN
61408(0xEFE0)Nodeosetof0
Source Address
(0x??(CSA*))
PDU Format
239(0xEF)
PDU Specic
224(0xE0)
Built Message
(0x18EFE0??)
Transmit rate
50 ms
Msg timeout
200 ms
Priority
6
DP
0
Command Value
82(0x52)
*CSA-ControllerSourceAddress
