8
4.2 CONFIGURING THE NODE ID
CAN
1 2
43
65
7 8
1 2 3 4 5 6
7 8 9 10 11 12
13
14
15 16 17 18
TheNodeIDisconguredbyjumperingthematchingCong-AtoCong-B.TheNodeIDstartswithabasesourceaddressof61408
(0xEFE0)withnojumpersinstalled.Theosetaddressisconguredwiththeuseofbinarycodeddecimal(BCD).Apowercycleis
requiredwhenchangingtheNodeID.Ifaduplicatesourceaddressisonthenetworkonapowerupourmodulewillstayinaddress
arbitration mode and will not function.
EXAMPLE
Jumpersfrompin2topin8(1’s)and
pin4topin10(4’s)oset=1+4=5
61408(baseaddress)+5(NodeID)=61413
(NodeID))
Node ID 1's 2's 4's 8's Node ID
Source
Address
0 0 0 0 0 61408 224
1 1 0 0 0 61409 225
2 0 1 0 0 61410 226
3 1 1 0 0 61411 227
4 0 0 1 0 61412 228
5 1 0 1 0 61413 229
6 0 1 1 0 61414 230
7 1 1 1 0 61415 231
8 0 0 0 1 61416 232
9 1 0 0 1 61417 233
10 0 1 0 1 61418 234
11 1 1 0 1 61419 235
12 0 0 1 1 61420 236
13 1 0 1 1 61421 237
14 0 1 1 1 61422 238
15 1 1 1 1 61423 239
Node ID (0-15 Oset) in BCD
Cong1-A(pin2)toCong1-B(pin8)=1’s
Cong2-A(pin3)toCong2-B(pin9)=2’s
Cong3-A(pin4)toCong3-B(pin10)=4’s
Cong4-A(pin5)toCong4-B(pin11)=8’s
Cong1-A
Cong2-A
Cong3-A
Cong4-A
Cong1-B
Cong2-B
Cong3-B
Cong4-B
Please note that all devices on the same
J1939 network must have a dierent Node ID
All unused pins need to be plugged with a
Deutsch #114017 sealing plug to maintain
the IP67 rating
