A Murrelektronik Company
A Murrelektronik Company
7
4.1 CONFIGURING THE BAUD RATE
Conguration & Power Plug
CAN
1 2
43
65
7 8
1 2 3 4 5 6
7 8 9 10 11 12
13
14
15 16 17 18
Congurationofthebaudrateisdoneusingpins1&7ofthePowerandCongurationplugshownbelow.Currentlythereare2
baudratessupported,250kband500kb.Ifyouareconnectingtoa250kbnetworknojumpersarerequired.Ifconnectingtoa500kb
network,jumperpin1topin7.
Baud1-A
Baud1-B
Baud Rate
NoJumper=250kb
Baud1-AtoBaud1-B=500kb
Please note that all devices on the same
J1939 network must have the same baud rate
All unused pins need to be plugged with a
Deutsch #114017 sealing plug to maintain
the IP67 rating
A power cycle is required to “set” the baud
rate.
