A Murrelektronik Company
A Murrelektronik Company
37
5.5 DATA SHEET
Conguration & Power Plug
CAN Ports 1 & 2 Non-Isolated
CAN
1 2
43
65
7 8
1 2
4 3
CAN
(J1939)
Pin2=CANHigh
Pin4=CANLow
Power
(Module&Input-13A)
Pin1=8-32VDC
Pin3=Ground(A)
CAN
1 2
43
65
7 8
1 2 3 4 5 6
7 8 9 10 11 12
13
14
15 16 17 18
See page 33 for pinout guide
Outputs (Ports 1-4)
CAN
1 2
43
65
7 8
1 2
4 3
Ground(B)
OutputB(4A)
OutputA(4A)
Ground(B)
Inputs (Ports 5-8)
CAN
1 2
43
65
7 8
1 2
4 3
Ground(A)
Input B
Input A
8-32VDCPower
5.5.1 PORT CONFIGURATION
