Murr Elektronik Data Panel xtreme DB DP-34044-1 User Manual

36
Status Message 2 (Conguration and Output Status)
PGN Name Data Type Byte Bits Description
65531(0xFFFB) CongPair1
2 Bit
1
1,2 Baudratecongurationjumperisapplied
CongPair2 3,4 NodeID1'scongurationjumperisapplied
CongPair3 5,6 NodeID2'scongurationjumperisapplied
CongPair4 7,8 NodeID3'scongurationjumperisapplied
CongPair5
2
1,2 NodeID4'scongurationjumperisapplied
3,4
Notused,willsee(11b)5,6
7,8
Output 1A Status
3
1,2 StatusofOutput1A,(00=o),(01=on),(10=fault)
Output 1B Status 3,4 StatusofOutput1B,(00=o),(01=on),(10=fault)
Output 2A Status 5,6 StatusofOutput2A,(00=o),(01=on),(10=fault)
Output 2B Status 7,8 StatusofOutput2B,(00=o),(01=on),(10=fault)
Output 3A Status
4
1,2 StatusofOutput3A,(00=o),(01=on),(10=fault)
Output 3B Status 3,4 StatusofOutput3B,(00=o),(01=on),(10=fault)
Output 4A Status 5,6 StatusofOutput4A,(00=o),(01=on),(10=fault)
Output 4B Status 7,8 StatusofOutput4B,(00=o),(01=on),(10=fault)
5
1,2
Notused,willsee(11b)
3,4
5,6
7,8
6
1,2
3,4
5,6
7,8
Power Buss P1
2 Bit
7
1,2 StatusofPowerBussP1(00=o),(01=on),(10=fault)
Power Buss P2 3,4 StatusofPowerBussP2(00=o),(01=on),(10=fault)
5,6
Notused,willsee(11b)
7,8
SaveCong
Counter
Byte 8 Countofhowmanytimesthecongurationhasbeensavedtothemodule
Status Message 3 (Controller Information)
PGN Name Data Type Byte Bits Description
65532(0xFFFC) CNFG1
Byte
1
All
HardwareConguration
CNFG2 2 PCBAssemblyRevision
VBAT 10 Bit 3 BatteryVoltage100mV/bit,datarange0-320(32.0VDCmax).
4 1,2
TEMP 12 Bit 5 All ModuleTemperature,-100.0°Fto+300.0°F,datarange0–4000bits.
6 1,2,3,3
CNFG3 Byte 7
All
AdditionalConguration
8 NotUsed
