38
Conguration & Power Plug Pinouts
Power (Output Only)
Power1=13Aforports1&2(Outputs1A,1B,2A,2B)
Power2=13Aforports3&4(Outputs3A,3B,4A,4B)
Ground1B=forports1-4
Ground2B=forports1-4
Baud Rate
NoJumper=250kb
Baud1-AtoBaud1-B=500kb7.
Node ID (0-15)
Cong1-AtoCong1-B=1s
Cong2-AtoCong2-B=2s
Cong3-AtoCong3-B=4s
Cong4-AtoCong4-B=8s
CAN
1 2
43
65
7 8
1 2 3 4 5 6
7 8 9 10 11 12
13
14
15 16 17 18
Power
Pin1=Ground(B)
Pin3=Ground(B)
Congurations
1.Digitalhighside
2.PWM
3.PWM(i)CurrentControlled
Amperage
Alloutputs=4A
Outputs
•Port1,Pin4:Output1A
•Port1,Pin2:Output1B
•Port2,Pin4:Output2A
•Port2,Pin2:Output2B
•Port3,Pin4:Output3A
•Port3,Pin2:Output3B
•Port4,Pin4:Output4A
•Port4,Pin2:Output4B
Outputs (Ports 1-4)
Power
Pin1=8-32VDC
Pin3=Ground(A)
Congurations
Input A
1.DigitalPositive
2. Digital Ground
3.Frequency/Counter/Encoder(7A&8A)
Input B
1.DigitalPositive
2. Digital Ground
3.4-20mA
4.0-5VDC
5.0-10VDC
6.0-32VDC
7.Ratiometric
Inputs
•Port5,Pin4:Input5A
•Port5,Pin2:Input5B
•Port6,Pin4:Input6A
•Port6,Pin2:Input6B
•Port7,Pin4:Input7A
•Port7,Pin2:Input7B
•Port8,Pin4:Input8A
•Port8,Pin2:Input8B
Inputs (Ports 5-8)
1.Baud1-A
2.Cong1-A
3.Cong2-A
4.Cong3-A
5.Cong4-A
6.N/C
7.Baud1-B
8.Cong1-B
9.Cong2-B
10.Cong3-B
11.Cong4-B
12.N/C
13. Power 1
14. Power 2
15.N/C
16.Ground(B)
17.Ground(B)
18.N/C
