51
StatusMessage3(ControllerInformation)
PGN
65523(0xFFF3)
Source Address
224(0xE0)
PDU Format
255(0xFF)
PDU Specic
243(0xF3)
Built Message
(0x18FFF3E0)
StatusMessage4(OutputAmperageFeedbackOUT1A-2B)
Name Data Type Byte Bits Description
OUT1AAMPFEEDBACK Word 1 CurrentreadingonOutput1A,0-4,000=0-4000mA
2
OUT1BAMPFEEDBACK Word 3 CurrentreadingonOutput1B,0-4,000=0-4000mA
4
OUT2AAMPFEEDBACK Word 5 CurrentreadingonOutput2A,0-4,000=0-4000mA
6
OUT2BAMPFEEDBACK Word 7 CurrentreadingonOutput2B,0-4,000=0-4000mA
8
PGN
65524(0xFFF4)
Source Address
224(0xE0)
PDU Format
255(0xFF)
PDU Specic
243(0xF4)
Built Message
(0x18FFF4E0)
StatusMessage5(OutputAmperageFeedbackOUT3A-4B)
Name Data Type Byte Bits Description
OUT3AAMPFEEDBACK Word 1 CurrentreadingonOutput3A,0-4,000=0-4000mA
2
OUT3BAMPFEEDBACK Word 3 CurrentreadingonOutput3B,0-4,000=0-4000mA
4
OUT4AAMPFEEDBACK Word 5 CurrentreadingonOutput4A,0-4,000=0-4000mA
6
OUT4BAMPFEEDBACK Word 7 CurrentreadingonOutput4B,0-4,000=0-4000mA
8
Transmit rate
50 ms
Msg timeout
200 ms
Priority
6
DP
0
Transmit rate
50 ms
Msg timeout
200 ms
Priority
6
DP
0
Name Data Type Byte Bits Description
CNFG1
Byte
1
All
HardwareConguration
CNFG2 2 PCBAssemblyRevision
VBAT 10 Bit 3 BatteryVoltage
4 1,2
TEMP 12 Bit 5 All ModuleTemperature
6 1,2,3,3
CNFG3 Byte 7
All
AdditionalConguration
8 NotUsed
PGN
65532(0xFFFC)
Source Address
224(0xE0)
PDU Format
255(0xFF)
PDU Specic
252(0xFC)
Built Message
(0x18FFFCE0)
Transmit rate
50 ms
Msg timeout
200 ms
Priority
6
DP
0
