ValueCut User Manual
Installation 2-9
Step 3
Insert the basket rods to the basket holes (See Figure 13)
Step 4
Loosen the basket screws from the basket arms. Position the basket rod in front of the basket
arms and insert the basket screws into the holes on the basket rod and tighten them. (Figure
14)
Basket rods
Basket
Figure 2-13
Figure 2-14
Basket screw
Basket rod
Basket arm
