MUTOH ValueCut Series - 2.5 Cutting Pad Installation

ValueCut User Manual
Installation 2-11
2.5 Cutting Pad Installation
1 piece of cutting pad is included in the accessory pack. Follow the instruction below to install
a new cutting pad when the existing pad is worn out.
Step 1
Carefully remove the cutting pad from the unit.
Figure 2-16
Step 2
Remove the remaining adhesive on the groove with alcohol or cleaning naphtha.
Remaining adhesive
Figure 2-17
Remaining adhesive
