3.3 Menu in Off-line Mode
Press [ON/OFF LINE] to switch to the offline mode
Draft, Fair, Normal, Fine, Small Letter
Offline For System Setup
[ FORCE]
5~600 with an increment of 5(gram force)
[ OFFSET ]
[ DATA CLEAR ]
Clear Data Memory
N:Cancel OK:ENTER
move origin
X
:
Y
:
[ ]
Speed: 72 cm/s
Select: OK:ENTER
Speed:3~153 with an increment of 3(cm/s)
Force:80 gf
OK:ENTER
Offset: 0.275 mm
OK:ENTER
0.000~1.000 with an increment of 0.025(mm)
[ SPEED ]
UP Speed: 72 cm/s
Select: OK:ENTER
UP Speed :3~153 with an increment of 3(cm/s)
Quality: normal
Select: OK:ENTER
Ratio: 100%, 200%, 300%, 400%
Pattern: Cross, Arrow
Pattern: Arrow
Change: OK: ENTER
Square Cut
Select: OK:ENTER
[CUT TEST ]
Turn CW , Turn CCW
Pattern Setting
Select: OK:ENTER
Repeat Last Plot
Select: OK:ENTER
Ratio Setting
Select: OK:ENTER
Ratio: 100%
Change: OK: ENTER
Blade Length Adjust
Select: OK:ENTER
Set Length 0.00mm
Change: OK: ENTER
Test Blade Holder
OK: ENTER
Test Blade Length
OK: ENTER
Repeat AAS Job
Select: OK:ENTER
