ValueCut User Manual
Accu-Aligning System
5-7
5.4 Contour Cutting
For accurate contour cutting with AAS function, please proceed the following steps:
Step 1 Creating Graphics
Create the graphic that you want to print and cut in your software.
Create a contour for cutting around the graphic.
TIPS1: Leave some space between the graphic and contour line.
TIPS2: Create the contour in a separate layer and assign a different color for it.
Add registration marks around the graphic.
Note:
Before adjusting the AAS II settings, please proceed scaling for width and length.
The blade offset value isn’t set for this test graphic, please set it according to the blade
you use.
If you have any question, please contact us or your local distributor for assistance.
