MUTOH ValueCut Series - 3.2 Menu in On-line Mode

ValueCut User Manual
The Control Panel 3-2
3.2 Menu in On-line Mode
Power On ValueCut in processing
ValueCut
Firmware: Copyright:
Place Media And Then Lower
Down The Lever
Roll Edge Single
Sizing Media Width Lever Up
To Abort
Sizing Media Length Lever Up
To Abort
Pause Setup Resume
S--- F----- O----
L
--------
W
-----
T1M
Sending data
[PAUSE ]
[ FORCE]
Force:80 gf
OK:ENTER
use to select; [ENTER] to enable the setting
[ SPEED ]
Speed: 72 cm/s
Select:
OK:ENTER
UP Speed: 72 cm/s
Select: OK:ENTER
Quality: normal
Select: OK:ENTER
[ OFFSET ]
Offset: 0.275 mm
OK:ENTER
[ DATA CLEAR ]
Clear Data Memory
N:Cancel OK:ENTER
[TOOL SELECT ]
1S:72 F:80 O:0.275 M
Select: OK:ENTER
Set Smoothing Cut
Select:
OK:ENTER
OverCut:
0.00mm
Select: OK:ENTER
Pouncing 0 mm
Select: OK:ENTER
Top menu
Set Tangential Mode
Select:
OK:ENTER
use
to select
ValueCut Cutter
LCM Version- - -
Speed--- Force----- Offset---- Length---- Width----Tool set----Metric
