4.2 Tracking Performance
In order to achieve the best tracking performance for a long plot, we recommend some
significant media loading procedures described as follows:
If the media length is less than 4 meters, leave the margin of 0.5mm—25mm in the left and right
edges of the media (Figure 4-12).
If the media length is greater than 4 meters, leave at least 25mm margin on the left and right
edges of the media (Figure 4-13).
Please refer to the paragraph “4.5 How to Make A Long Plot” for more details.
Figure 4-12
Pinch roller
