MX T406 - Pch System; Bucket Position; Pallet Position

38
Subject to modication
14. PCH System
The Hydraulic Compensation Parallelogram (PCH) operates
automatically (optional).
The system is tted with hydraulic safety features to protect it
from any malfunction. Two user positions of the PCH System are
available.
■
1
2
(1) “Bucket” position
(2) “Pallet” position
14.1 “Bucket” position
The PCH System keeps the bucket at the same angle while the
loader is lifting or lowering.
This means that loaded materials will not spill out, either forwards
or backwards.
■
14.2 “Pallet” position
The PCH System keeps the pallet attachment level while the loader
is lifting or lowering.
This means that material loaded level on the ground will remain
horizontal.
■
