7. Loader hitching
This operation must be carried out by the driver, who must exit the cab and ensure all
manoeuvres are prohibited while working on the loader.
Watch the unhitching/hitching video at www.m-x.eu
— Check that the locking indicators on the left and right frames are
in the red zone, and that no object is present to inhibit the loader
connection.
— The bracket heads are provided with a ramp and a roller for
raising the loader to the hitch.
■
— Move the tractor forwards, guiding the loader frame onto the
bracket until the catches automatically trip.
■
— The loader is locked when the locking indicators are in the
green zone.
IMPORTANT: If the indicators are still in the red zone, please refer
to the section "Two-step hitching".
■
