T406 T406+ T408 T408+ T410 T410+ T412 T412+ T414
T417/
T418
Length (A) 2.30 m 2.30 m 2.40 m 2.40 m 2.50 m 2.50 m 2.60 m 2.60 m 2.75 m 2.75 m
Width (B) 1.18 m 1.18 m 1.18 m 1.18 m 1.18 m 1.18 m 1.18 m 1.18 m 1.18 m 1.18 / 1.38 m
Height (C) 1.72 m 1.72 m 1.78 m 1.78 m 1.83 m 1.83 m 1.87 m 1.87 m 2.05 m 2.05 m
Min. weight (with no option) 460 kg 461 kg 480 kg 500 kg 535 kg 550 kg 550 kg 550 kg 630 kg 660 / 697 kg
Max. weight 590 kg 590 kg 632 kg 632 kg 680 kg 680 kg 707 kg 707 kg 821 kg 844 / 827 kg
Max. height at implement pivot* 3.75 m 3.75 m 3.85 m 3.85 m 4.00 m 4.00 m 4.15 m 4.15 m 4.50 m 4.60 m
Max. height under horizontal bucket (1) # 3.50 m 3.50 m 3.60 m 3.60 m 3.75 m 3.75 m 3.90 m 3.90 m 4.25 m 4.35 m
Max. height under dumped bucket (2) # 2.95 m 2.95 m 3.05 m 3.05 m 3.20 m 3.20 m 3.35 m 3.35 m 3.70 m 3.80 m
Digging depth (3) # 0.20 m 0.20 m 0.20 m 0.20 m 0.20 m 0.20 m 0.20 m 0.20 m 0.20 m 0.20 m
Dumping angle at full height (4) # 52° 52° 55° 55° 55° 55° 55° 55° 50° 50°
Crowding angle (5) # 47° 47° 52° 52° 52° 52° 52° 52° 51° 51°
Lifting force at implement pivot* 1900 kg 2200 kg 2100 kg 2400 kg 2400 kg 2750 kg 2750 kg 3100 kg 2670 kg 3430 kg
Lift capacity at implement pivot over the entire lifting range* 1500 kg 1750 kg 1890 kg 2200 kg 2190 kg 2500 kg 2450 kg 2780 kg 2320 kg 3050 kg
Payload on pallet at 0.60 m out on forks
On the ground 1450 kg 1690 kg 1850 kg 2010 kg 2080 kg 2420 kg 2410 kg 2610 kg 2360 kg 3040 kg
At 2 m above ground 1380 kg 1650 kg 1740 kg 2040 kg 2000 kg 2310 kg 2290 kg 2490 kg 2200 kg 2860 kg
At 3 m above ground 1350 kg 1620 kg 1650 kg 1950 kg 1980 kg 2270 kg 2230 kg 2430 kg 2150 kg 2700 kg
At max. height 1350 kg 1620 kg 1630 kg 1930 kg 1960 kg 2250 kg 2200 kg 2400 kg 2150 kg 2650 kg
Lifting time 3.9 sec 4.6 sec 4.6 sec 5.4 sec 5.4 sec 6.2 sec 6.2 sec 7.1 sec 6.4 sec 8.2 sec
Dumping time 0.7 sec 0.9 sec 1 sec 1 sec 1 sec 1.4 sec 1.4 sec 1.4 sec 1.4 sec 1.4 sec
NOTE: Specications determined at 190 bar pressure and with a ow rate of 60 litres/min.
Data may vary depending on the type of tractor being equipped. * Figures provided for a general purpose bucket.
Only payloads are counted. The gures at ground level and at the implement pivot axis are not to be used.
■
