W415-3031 / 04.30.21
EN
10
installation
2.4 installing the appliance onto the wall (wall mount)
• Consult your local builder before installing the appliance. Appliance must be installed in accordance with local
building codes.
• Appliance must be installed in a location not prone to moisture.
• Appliance must be installed at least 36" (91.4cm) away from combustible materials such as curtain drapes,
furniture, bedding, paper, etc.
!
WARNING
note:
We recommend having 2 people install this appliance.
Appliance Overview (Back View)
Side cover Side cover
Wall mount bracket
Top bracket
Mounting slots
1. Remove front glass (see "door glass removal" section). If applicable,
remove existing media.
2. Place appliance on a soft, non-abrasive surface then remove the side
covers secured to the back of the appliance. Set aside.
3. Remove the bottom bracket (Fig. 1). Set aside.
4. Hold the appliance against the wall to determine its final location.
Fig. 1
