W415-3031 / 04.30.21
EN
16
finishing
3.3 door glass removal
1. Remove the retainer bracket by removing the 2 screws (Fig. 1 and 2). Set the screws aside; keep the bracket
on-hand for Step 2.
CAUTION:
Using the bracket this way is only recommended for
ease of removal. When installing the bracket, hooks
must ALWAYS face toward the front of the appliance
(see "door glass installation" section). Failure to comply
with these instructions could create a fire hazard.
2. For ease of removal, use the bracket hooks to reach behind
the glass and pull it forward (Fig. 3).
3. Remove the glass and place it on a soft, non-abrasive surface.
Fig. 3
Bracket hook
Glass
Fig. 1
Some components
hidden for clarity
Fig. 2
FRONT OF APPLIANCE
FRONT OF APPLIANCE
FRONT OF APPLIANCE
