W415-2165 / G / 08.15.18

ﬁnishing

5.2 glass door removal and installation

A. To install the glass door, simply place the door on the holding pins on the bottom frame of the

appliance. Install the screw into the safety catch wire, slightly push the glass door into the frame and

latch it secure with the 2 top latches.

B. To remove the glass door, swing the top 2 latches to release the door. The door will hang slightly on

the the safety catch wire.

C. Place 1 hand on the glass door while removing the screw from the catch wire. Allow the door to pivot

slightly, hold the sides with both hands while lifting the door out of the appliance.

Safety Catch

Wire

Screw

Latch

The above is llustrated with latches visible.

LOCK

OPEN

Pin Hole

WARNING

• Glass may be hot. Do not touch glass until cooled.

• If equipped with door latches that are part of a safety system, they must be properly engaged. Do not

operate the appliance with latches disengaged.

• Facing and/or ﬁ nishing materials must not interfere with air ﬂ ow through air openings, louvre openings,

operation of louvres, or doors/access for service. Observe all clearances when applying combustible

materials.

• Before door is removed, turn the appliance off and wait until appliance is cool to the touch. Doors are heavy

and fragile so handle with care.

47.1

Pushing in on the door will make the latch swing easier.

note:
