Napoleon ASCENT SERIES User Manual

W415-2165 / G / 08.15.18
EN
8
general information
1.6 label location
PCB
Junction Box
A
B
C
D
E
F
G
H
I
J
Ref. Part Number Description
A W385-2090 Wire Diagram Label
B W385-1946 "Do Not Cover" Label
C* W385-1954 Door Latch Label
D** W385-2191 Serial Number (NEFB33H)
D** W385-2192 Serial Number (NEFB40H
E W385-2088 Rating Plate (NEFB33H)
E W385-2089 Rating Plate (NEFB40H)
F W385-1945 Caution Label
G W385-1944 Warning Label
H W385-2083 120V Hard Wiring Label
I W385-2084 240V Hard Wiring Label
J W385-1943 Warning Label
* Located on door glass.
** Located on top of door frame.

Napoleon ASCENT SERIES Specifications

General

Model	Ascent Series
Category	Indoor Fireplace
Fuel Type	Natural Gas or Propane
Ignition System	Electronic Ignition
Vent Type	Direct Vent
Fireplace Type	Direct Vent Gas Fireplace
Dimensions	Varies by model
Weight	Varies by model
Warranty	Limited Lifetime Warranty
Control Options	Remote Control
Viewing Area	Varies by model
