RED
GREEN
BLACK
WHITE
GREEN (G)
RED (L2)
BLACK (L1)
WHITE (N)
115
240V HARD WIRING CONNECTION
If it is necessary to hard wire this appliance, a qualified electrician must remove the cord connection, and wire the
appliance directly to the household wiring. The wire and double-pole power supply breaker must rated for 240V
minimum 15 Amps, maximum 20 Amps.
This appliance must be electrically connected and grounded in accordance with local codes, if hard wired. In the
absence of local codes, use the current CSA C22.1 CANADIAN ELECTRICAL CODE in Canada or the current
ANSI/NFPA 70 NATIONAL ELECTRICAL CODE in the United States.
RED
GREEN
BLACK
WHITE
GREEN (G)
RED (L2)
WHITE (N)
115
White, Black, Red and
Green wires:
Connect to 240V
power supply.
3.3.6 240V hard wiring installation
Wire Nut
W415-2165 / G / 08.15.18
EN
16
installation
Voltage Selector Switch
GREEN
BLACK
WHITE
FIREPLACE
JUNCTION
WIRE NUT
NEUTRAL
L1
GROUND
CONNECT TO
120V POWER
SUPPLY.
GREEN /
VERT
BLACK /
NOIR
WHITE /
BLANC
FIREPLACE
JUNCTION /
BOÎTE DE
JONCTION
WIRE NUT /
CAPUCHON DE CONNEXION
NEUTRAL
/
NEUTRE
L1
GROUND /
TERRE
CONNECT TO
120V POWER
SUPPLY MIN.
15AMPS /
RACCORDER À
LA SOURCE
D’ALIMENTATION
ÉLECTRIQUE DE
120 V, MIN.
15AMPS.
230
GREEN
BLACK
WHITE
FIREPLACE
JUNCTION
NEUTRAL
L1
GROUND
CONNECT TO
240V POWER
SUPPLY.
230
RED
WIRE NUT
L2
• Turn off the appliance completely and let cool before servicing. Only a qualified service person should service
and repair this electric appliance.
!
WARNING
There are 4 wires from the appliance junction: white (neutral), black (power L1), Red (Power L2) and green
(ground) that connect to 240V double-pole power supply (breaker panel).
note:
