PXIe-1095 User Manual

Figure 2-1. PXIe-1095 Chassis Minimum Cooling Clearances

101.60 mm

(4.00 in.)

44.45 mm

(1.75 in.)

44.45 mm

(1.75 in.)

PS TEMP FAN S

PXIe-1095

USE ONLY COMPATIBLE RACK MOUNT KITS.

COOLING CLEARANCE REQUIRED. SEE MANUAL.
