Table A-6. TP2 Connector Pinout for the System Timing Slot
Pin A B ab C D cd E F ef
1 NC NC GND PXIe_DSTARC8+ PXIe_DSTARC8- GND PXIe_DSTARB8+ PXIe_DSTARB8- GND
2 NC NC GND NC NC GND PXIe_DSTARA8+ PXIe_DSTARA8- GND
3 NC NC GND PXIe_DSTARC1+ PXIe_DSTARC1- GND NC NC GND
4 PXIe_DSTARB1+ PXIe_DSTARB1- GND PXI_STAR0 PXI_STAR1 GND NC NC GND
5 PXIe_DSTARA1+ PXIe_DSTARA1- GND PXI_STAR2 PXI_STAR3 GND NC NC GND
6 PXIe_DSTARC2+ PXIe_DSTARC2- GND PXI_STAR4 PXI_STAR5 GND NC NC GND
7 PXIe_DSTARB2+ PXIe_DSTARB2- GND PXI_STAR6 PXI_STAR7 GND NC NC GND
8 PXIe_DSTARA2+ PXIe_DSTARA2- GND PXI_STAR8 PXI_STAR9 GND PXIe_DSTARC11+ PXIe_DSTARC11- GND
9 PXIe_DSTARC3+ PXIe_DSTARC3- GND PXI_STAR10 PXI_STAR11 GND PXIe_DSTARA11+ PXIe_DSTARA11- GND
10 PXIe_DSTARB3+ PXIe_DSTARB3- GND NC NC GND PXIe_DSTARB11+ PXIe_DSTARB11- GND
