Appendix A Pinouts
A-6 | ni.com
Table A-7. XP3 Connector Pinout for the System Timing Slot
Pin A B ab C D cd E F ef
1 PXIe_CLK100+ PXIe_CLK100- GND PXIe_SYNC100+ PXIe_SYNC100- GND PXIe_DSTARC+ PXIe_DSTARC- GND
2 PRSNT# PWREN# GND PXIe_DSTARB+ PXIe_DSTARB- GND PXIe_DSTARA+ PXIe_DSTARA- GND
3 SMBDAT SMBCLK GND RSV RSV GND RSV RSV GND
4 MPWRGD* PERST# GND RSV RSV GND 1RefClk+ 1RefClk- GND
5 1PETp0 1PETn0 GND 1PERp0 1PERn0 GND 1PETp1 1PETn1 GND
6 1PETp2 1PETn2 GND 1PERp2 1PERn2 GND 1PERp1 1PERn1 GND
7 1PETp3 1PETn3 GND 1PERp3 1PERn3 GND 1PETp4 1PETn4 GND
8 1PETp5 1PETn5 GND 1PERp5 1PERn5 GND 1PERp4 1PERn4 GND
9 1PETp6 1PETn6 GND 1PERp6 1PERn6 GND 1PETp7 1PETn7 GND
10 RSV RSV GND RSV RSV GND 1PERp7 1PERn7 GND
