© National Instruments | A-7
PXIe-1095 User Manual
Hybrid Slot Pinouts
Table A-8. XP4 Connector Pinout for the System Timing Slot
Pin Z A B C D E F
1 GND GA4 GA3 GA2 GA1 GA0 GND
2 GND 5Vaux GND SYSEN# WAKE# ALERT# GND
3 GND 12V 12V GND GND GND GND
4 GND GND GND 3.3V 3.3V 3.3V GND
5 GND PXI_TRIG3 PXI_TRIG4 PXI_TRIG5 GND PXI_TRIG6 GND
6 GND PXI_TRIG2 GND ATNLED PXI_CLK10_IN PXI_CLK10 GND
7 GND PXI_TRIG1 PXI_TRIG0 AT N SW # GND PXI_TRIG7 GND
8 GND PXIe_SYNC_CTRL GND RSV PXI_LBL6 PXI_LBR6 GND
Table A-9. P1 Connector Pinout for the Hybrid Slot
Pin Z A B C D E F
25 GND 5V REQ64# ENUM# 3.3V 5V GND
24 GND AD[1] 5V V(I/O) AD[0] ACK64# GND
23 GND 3.3V AD[4] AD[3] 5V AD[2] GND
22 GND AD[7] GND 3.3V AD[6] AD[5] GND
21 GND 3.3V AD[9] AD[8] M66EN C/BE[0]# GND
20 GND AD[12] GND V(I/O) AD[11] AD[10] GND
19 GND 3.3V AD[15] AD[14] GND AD[13] GND
18 GND SERR# GND 3.3V PA R C/BE[1]# GND
17 GND 3.3V IPMB_SCL IPMB_SDA GND PERR# GND
16 GND DEVSEL# GND V(I/O) STOP# LOCK# GND
15 GND 3.3V FRAME# IRDY# BD_SEL# TRDY# GND
12 to 14 Key Area
11 GND AD[18] AD[17] AD[16] GND C/BE[2]# GND
10 GND AD[21] GND 3.3V AD[20] AD[19] GND
9 GND C/BE[3]# IDSEL AD[23] GND AD[22] GND
8 GND AD[26] GND V(I/O) AD[25] AD[24] GND
7 GND AD[30] AD[29] AD[28] GND AD[27] GND
6 GND REQ# GND 3.3V CLK AD[31] GND
To Next Page
