Table 2. NI sbRIO Connector Descriptions
Connector Description Manufacturer,
Part Number
Recommended
Mating
Connector
NI
Solution
Power 2-position, mini-fit JR,
H = 10.439 mm (0.411 in.)
Molex,
46999-0144
Molex,
50-36-1673 w/
0457501211
NI, Power
Plug
Assembly,
152834-01
RS-232/C
AN IDC
Header
10-pin, 0.100 in. CT,
shrouded,
H = 9.398 mm (0.370 in.)
Samtec,
TST-105-01-L-D
Tyco, 1658622-1 NI, 10-pin
to 9-pin D-
SUB,
153158-10
RMC
Connector
240-pin, 40 × 6 position,
high density open pin field
SEARAY
Samtec,
SEAF-40-06.5-
S-06-2-A-K-TR
Samtec,
SEAM-40-03.0-
S-06-2-A-K-TR
Samtec SEAM connectors come in multiple heights, indicated in millimeters by the XX.X
portion of the SEAM-40-XX.X-S-06-2 example part number. You can order a mating
connector for the RMC connector from Samtec, the connector manufacturer, or from a
distributor such as Arrow or Avnet.
The height of the mating connector you select to mate to the RMC connector determines the
height of the standoffs you need. Samtec requires that standoffs be 0.15 mm (0.006 in.) taller
than the combined height of the RMC and mating connectors. Therefore, to determine the
required standoff height, you must add the heights of the connectors plus 0.15 mm (0.006 in.).
The following table provides an example standoff height calculation using a Samtec
SEAM-40-03.0-S-06-2-A-K-TR mating connector.
Table 3. Example Connector Configuration and Calculated Standoff Height
Component Manufacturer, Part Number Height
RMC connector Samtec SEAF-40-06.5-S-06-2-A-K-
TR
6.50 mm (0.256 in.)
Mating connector Samtec SEAM-40-03.0-S-06-2-A-K-
TR
3.00 mm (0.118 in.)
NI sbRIO-9607 User Manual | © National Instruments | 19
