multi-regional buffers on a specific bank of pins. Each MRCC pin has an _MRCC suffix in
the pin name.
Tip FPGA DIO pins through the RMC may be used to import or export
clocks. Use the CLIP generation wizard to configure DIO lines for this
capability. NI recommends that you use the SRCC or MRCC pins when you
import a clock into LabVIEW FPGA.
Additional UART (4 RS-232 and 2 RS-485) Support
You must connect each of these interfaces to an appropriate RS-232 or RS-485 serial
transceiver on your RMC design. The NI sbRIO-9607/9627 RMC Design Guide on ni.com/
manuals provides design guidelines, requirements for routing signals, and recommendations
for a serial transceiver. The specifications depend on a suitable RMC design that follows these
guidelines, requirements, and recommended or equivalent transceivers. Refer to RS-232 (DTE)
Serial Port and RS-485 Serial Port section in the NI sbRIO-9607 Specifications on ni.com/
manuals for the specifications.
CAN Support
You must connect this interface to an appropriate CAN transceiver on your RMC design. The
NI sbRIO-9607/9627 RMC Design Guide on ni.com/manuals provides design guidelines,
requirements for routing signals, and recommendations for a CAN transceiver. The
specifications depend on a suitable RMC design that follows these guidelines and
requirements and utilizes the recommended or an equivalent transceiver. Refer to Embedded
CAN section in the NI sbRIO-9607 Specifications on ni.com/manuals for the specifications.
SDIO Support
The sbRIO-9607 RMC provides a Secure Digital (SD) Card interface. The
NI sbRIO-9607/9627 RMC Design Guide on ni.com/manuals provides design guidelines,
requirements for routing signals, requirements for pull-up resistors, and recommendations for
an appropriate connector. Refer to SD Card Slot in the NI sbRIO-9607 Specifications on
ni.com/manuals for the specifications.
Power Requirements
The NI sbRIO device requires a 9 VDC to 30 VDC external power supply.
The NI sbRIO device filters and regulates the supplied power and provides power for RMCs.
Wiring the Power Supply Connector
Wire the power supply connector as shown in the following figure.
