Nautilus E916 - Page 48

48
SRVC#
WRNTY-
CODE
PART NO. / LEVEL DESCRIPTION
-1 -2 -3 -4
NA
1
25611 ASSEMBLY, RESISTOR, 3800
SM13580
1
13580 WASHER,#8 SAE FLAT
SM22109
1
22109 WASHER, #8 INTERNAL TOOTH LOCK
SM22110
1
22110 NUT,#8-32,HEX MACH
SM22134
1
22134 SCREW,#8-32 X .38,PHIL PAN HD
SM23783
1
23783 ASSY,CABLE,RESISTOR
SM24989
1
24989 RESISTOR,0.5 OHM, 240 WATT
SM40604
1
40604 BRACKET,RESISTOR,HEAT SHIELD
SM40632
1
40632 SCREW,.250-20UNC X .75LG SHC
SM40605
3
40605 WELDMENT, INT PULLEY TENSIONER
SM40607 40607 HUB,INTERMEDIATE PULLEY SHAFT
SM40631 40631 ASSY,INTERMED PULLEY BRACKET
NA 25218 NUT,SELF CLINCHING,.250-20
NA 25325 PEM NUT, 3/8-16
NA 40606 BRACKET,INTERMED PULLEY TENSIO
SM40608
1
40608 SHAFT,INTERMEDIATE PULLEY
SM40609
1
40609
SPACER,INTERMEDIATE SHAFT,LEFT
SM40610
1
40610
SPACER,INTERMEDIATE SHAFT,RIGH
SM40611
1
40611
SHAFT,CRANK
SM40654
1
40654 SCREW,10-32X.75,PANHD W/LK WAS
SM40678
1
40678 CABLE,ASSY,BATTERY,ELLIPTICAL
SM40734
1
40734 BEARING,1” PILLOW BLOCK,NO COL
SM40844
1
40844 CABLE ASSY,MAIN LOWER,EV916
SM40909
1
40909 BELT,POLY-V,61”,J,10 RIBS
SM40910
1
40910 BELT,POLY-V,38”,J,6 RIB
SM40952 40952 ASSEMBLY,INTERMEDIATE PULLEY
NA
1
12221 INTERMEDIATE PULLEY, MOLDED
NA 12347 HUB, INTERMEDIATE PULLY
SM23322
1
23322
BEARING, BALL 17MM X 40MM
SM40953 40953 ASSEMBLY,ALTERNATOR
SM20205
1
20205 ALTERNATOR,PRESTOLITE,1992
SM21204
1
21204 ASSY,FIELD,DIODE
NA 20456 CONNECTOR, LUG 18-22 AWG
NA 20751 TERMINAL,#10 RING,16-22 AWG
NA 22261 DIODE, IN5404
SM21445
1
21445 ASSY.,SPEED SENSOR,CLIM.SYS,CL
NA 21126 CONNECTOR,2-POS SOCKET HOUSING
