Nautilus® Commerical Series Elliptical Service Manual
SRVC#
WRNTY-
CODE
PART NO. / LEVEL DESCRIPTION
-1 -2 -3 -4
NA 21127 CONNECTOR, SOCKET
NA 24594 SENSOR, INDUCTIVE
SM21778
1
21778 NUT,FLANGE (ALT-FLYWHEEL)
SM22027
1
22027 WASHER,.250 SPLIT LOCK
SM22036
1
22036 NUT,.250-20,NYLON INSERT
SM22047
1
22047 WASHER,FLAT,1/4 ID X 5/8 OD
SM22164
1
22164 SCREW,.250-20X1.25,HEX HD CAP
SM22517
1
22517 DISK,SPEED,SENSOR,4400CL
SM22884
1
22884 CLAMP,CABLE,11/16” DIA.
SM40329
1
40329 FLYWHEEL, CAST, 5300
SM40954 40954 ASSEMBLY,FRONT MAST
SM12497
2
12497 CONTACT PLATE, CHR
SM12506
2
12506 ADHESIVE TRANSFER TAPE, 5 MIL
SM17686
1
17686 LEVELING PAD
SM22027
1
22027 WASHER,.250 SPLIT LOCK
SM22028
1
22028 SCREW,.250-20X.63,HEX HD CAP
SM22047
1
22047 WASHER,FLAT,1/4 ID X 5/8 OD
SM24049
1
24049
SNAP RING, EXTERNAL, 1.50 DIA.
SM24279
1
24279 TYRAP,.14x11.0
SM24432
1
24432 WASHER,#10 SAE FLAT,ZINC PLATD
SM25165
1
25165 RECEIVER,PLUG-IN,POLAR
SM40464
2
40464 DECAL,CONSOLE BACK
SM40551
2
40551 COVER,ERGOBAR,FRONT
SM40552
2
40552 COVER,ERGOBAR,BACK
SM40567
2
40567 COVER,SWING ARM,TOP
SM40568
2
40568 COVER,SWING ARM,TOP,WITH INSER
SM40576
2
40576
HOUSING,CHR,FIXED,TOP
SM40577
2
40577
HOUSING,CHR,FIXED,BOTTOM
SM40639
1
40639 SCREW,6-32 X .438 LG SHC
SM40651
1
40651 WASHER,NYLATRON,1.505 X 2.250
SM40652
1
40652 WASHER,WAVE,1.560 X 1.8750 X
SM40654
1
40654 SCREW,10-32X.75,PANHD W/LK WAS
SM40679
1
40679 CABLE,ASSY,T-BAR GRIP TO CONSO
SM40710
1
40710 CABLE ASSY,CONSOLE-INLINE,ELLI
SM40776
1
40776 ADHESIVE,TRANSFER TAPE,25 MIL
SM40777
1
40777 SCREW,6-32 X 1.5” LG HEX SHC
SM40836
1
40836 ASSY,CABLE, VSL PLUG-IN, POLAR
