Nautilus® Commerical Series Elliptical Service Manual
SRVC#
WRNTY-
CODE
PART NO. / LEVEL DESCRIPTION
-1 -2 -3 -4
SM40776
2
40776 ADHESIVE,TRANSFER TAPE,25 MIL
SM40895
3
40895 WELDMENT,UPPER BODY, LEFT, V2
NA 40571 PLATE,UPPER BODY HANDLE,TOP
NA 40653 TUBE, CHR, UPPER BODY HANDLE
NA 40905 TUBE, UPPER BODY, LEFT, V2
SM40958 40958 ASSEMBLY,FOOT LINK, RIGHT
SM40424
2
40424 HOUSING,FOOT PAD,RIGHT
SM40434
2
40434 FOOT PAD,RIGHT
SM40443
1
40443 SCREW,10-32 X 1.0, OVAL HD,PHL
SM40646
1
40646 SHAFT,FOOT PIVOT
SM40667
1
40667 SCREW, 5/16-18X.75,BH CAP,SS
SM40668
1
40668 WASHER,FLAT,11/32IDX3/4ODX.050
SM40669
1
40669 WASHER,SPRING LOCK,5/16,SS
SM40877
3
40877 WELDMENT,FOOT SUPPORT,RIGHT,V5
NA 40798 BRKT,MTING,CONN ARM,FRONT,R,V2
NA 40883 SHAFT,CONNECTING ARM,FRONT,V3
NA 40914 ASSY,BRACKT,FOOT SUPRT,W/PEM,R
NA 40912 BRACKT,FOOT SUPPORT,1 TAB,R,V2
NA 41145 NUT,SELF-CLINCHING,10-32
SM40960 40960 ASSY,FOOT LINK W/BEARING,RIGHT
NA
1
40591 BEARING, IGUS JFI-141618-11
NA
3
40898 WELDMENT, FOOT LINK, RIGHT, V2
NA 40444 BRACKET,MOUNTING,LEG LINK
NA 40584 PLATE,SUPPORT,FOOT PIVOT,SIDE
NA 40585 HOUSING, BEARING, FOOT PIVOT
NA 40586 PLATE,SUPPORT,FOOT PIVOT,FRONT
NA 40587 PLATE,SUPPORT,FOOT PIVOT,REAR
NA 40588 BRACKET,FOOT LINK,MISALIGNMENT
NA 40589 GUSSET,FOOT LINK,MISALIGNMENT
NA 40904 TUBE, FOOT LINK, V2
SM40959 40959 ASSEMBLY,FOOT LINK,LEFT
SM40425
2
40425 HOUSING,FOOT PAD,LEFT
SM40435
2
40435 FOOT PAD,LEFT
SM40443
1
40443 SCREW,10-32 X 1.0, OVAL HD,PHL
SM40646
1
40646 SHAFT,FOOT PIVOT
SM40667
1
40667 SCREW, 5/16-18X.75,BH CAP,SS
SM40668
1
40668 WASHER,FLAT,11/32IDX3/4ODX.050
