Nautilus E916 - Page 52

52
SRVC#
WRNTY-
CODE
PART NO. / LEVEL DESCRIPTION
-1 -2 -3 -4
SM40669
1
40669 WASHER,SPRING LOCK,5/16,SS
SM40876
3
40876 WELDMENT,FOOT SUPPORT, LEFT,V5
NA 40797 BRKT,MTING,CONN ARM,FRT,L,V2
NA 40883 SHAFT,CONNECTING ARM,FRONT,V3
NA 40913 ASSY,BRACKT,FOOT SUPRT,W/PEM,L
NA 40911 BRACKT,FOOT SUPPORT,1 TAB,L,V2
NA 41145 NUT,SELF-CLINCHING,10-32
SM40961 40961 ASSY,FOOT LINK W/BEARING,LEFT
NA
1
40591 BEARING, IGUS JFI-141618-11
NA
3
40897 WELDMENT, FOOT LINK, LEFT, V2
NA 40444 BRACKET,MOUNTING,LEG LINK
NA 40584 PLATE,SUPPORT,FOOT PIVOT,SIDE
NA 40585 HOUSING, BEARING, FOOT PIVOT
NA 40586 PLATE,SUPPORT,FOOT PIVOT,FRONT
NA 40587 PLATE,SUPPORT,FOOT PIVOT,REAR
NA 40588 BRACKET,FOOT LINK,MISALIGNMENT
NA 40589 GUSSET,FOOT LINK,MISALIGNMENT
NA 40904 TUBE, FOOT LINK, V2
SM40962
1
40962 WASHER,NEOPRENE
SM41531
1
41531 CONSOLE, C51, LCD, E916
Service Parts List - E916
