NavigateWorx NR500 Series User Manual

Industrial Cellular VPN Router NR500 Series User Manual
Page 16 / 78
• Power Input
PIN
Description
V+ (Red line)
Positive
V- (Yellow line)
Negative
PGND
GND
2.5 Reset Button
Function
Action
Reboot
Press the RST button within 3s under operation status
Factory Reset
Press the RST button between 3s to 10s, all LED blink few times then
reboot automatically.
2.6 Insert SIM card
• Insert / Remove SIM card
1. Make sure the power is disconnected.
2. Use a Philips-head screwdriver to remove SIM slot cover.
3. Insert the SIM card(s) in to the SIM sockets.
4. Replace the SIM slot cover.
