NCR P1235 e*SmartClock Installation Guide, Ver. 1.1
US-IT Restaurant Architecture Team
Page 6 of 37 12/6/16
6. e*SmartClock Contents Checklist
• Unpack the e*SmartClock solution box & strip plastic from the new equipment’s
• Check for any damage during shipment, Report damage (if any) immediately to the shipping company
• Make sure the items in the carton match your order
6.1 Wall Mount Contents Checklist – Provided
The following contents must be available before the Installation process can begin.
Quantity
Item Description
Checklist
1
NCR P1235
(
7745
-
3100
-
0069
)
e*SmartClock
with integrated biometric
reader,
• 12" LCD, PCAP Touch
• Motherboard Braswell Quad N3160
• Memory, 4GB Base DDR3
• 2.5 inch; 60GB SSD
• No Stand
• Windows Embedded POSReady 7 (32bit)
1
Digital Persona: U4500 Fingerprint Reader
-
U.are.U® 4500 Reader
(Integrated)
1
Low profile w
all
-
mount
assembly k
it
(
7761
-
K003
)
containing
:
• Wall Mount Bracket
• Monitor Mount Bracket
• AC Adapter Bracket
• Power Brick Bracket; 2 - #8 screws
• Biometric Finger Reader Mounting HW
• Hardware Bag - Hardware Bag for bracket assembly and mounting
plate
• Metric Hardware Bag - Used to mount display
4
3 ft.
Panduit Wire
Raceway
(
JS130WR
)
-
7182
-
K101
-
V001
1
50' Yellow CAT5e Pre
-
Terminated
Patch
Cord
(
50UTPYL
)
-
7182
-
K102
-
V001
1
Epson TM
-
L90 Plus, with parallel and USB I/F with Power Brick
(C31C414A9972) - 7182-0094-9905
Note: Printer is optional but may be required due to State regulations.
1
Epson TM
-
L90 Printer Bracket
(MWBP)
-
only
required if printer is ordered
-
7182-K107-V001
• Wall Mount Printer Bracket
• Hardware Bag
1
Industrial Velcro Strips (Dual Lock), 1" x 3
” (
12 pieces / 6 pairs)
-
7182
-
K103-V001
1
USB ‘A’ to USB ‘B’
printer cable
, 3 ft.
-
only required if printer is ordered
-
7182-K104-V001
e*
SmartClock Manuals
1
e
*
SmartClock documentation manuals
6.2 Parts Not Included
Parts not included, but will need to be purchased:
•
Screws for studs
Depending on wall type, screws or lag bolts
are acceptable.
