Section 4: SpeciÞcations and Parts List
214 Product Description
Aspire S System SpeciÞcations
Aspire S System Capacities
Cabinets 1
Analog Trunks (CO/PBX lines) 8
Digital Key Telephones
Analog Single Line Telephones
IP Telephones
Virtual Extensions
24*
18*
16 *
24
* combined total to 26
(includes extension ports
provided on the CPU)
24-Button DLS Consoles
110-Button DSS Consoles
24
4
1 maximum per extension
4 maximum per extension.
Conference Circuits 32 (32-parties max per Conference)
ADA Adapter 24 installs on a keyset
ADA2 Adapter 16 installs on an IP keyset
APA Adapters 24 installs on a keyset
APR Adapters B1 = 24
B2 = 8 prior to software 2.50 /
16 with software 2.50+
installs on a keyset
CT-11 Cordless Headset Telephone 5 start with 3 - increase if no
interference experienced
CTA Adapter 24 installs on a keyset
CTU Adapter 24 installs on a keyset
Handsfree Adapter (HF-R) 24 installs on a keyset
IP Adapter 16 installs on a keyset
IP Power Failure Adapter (PSA) 16 installs on an IP keyset
Power Failure Telephones 2 provided by COIU PCBs
SLT Adapter 8
2PGDAD Modules 10 (4 for ACI ports, 4 for Door Boxes,
4 for Pages)
combined total to 10
Door Box/Door Unlock Contacts
Internal Page Zones
External Page Zones
4
8
8
Dial Tone Detector Circuits
DTMF Receiver Circuits
16*
16*
combined total to 16
Universal PCB slots 6
* NOTE: Maximum capacities above are determined by maximum PCB conÞguration allowed. When
installing single line sets or DISA, CPU circuits must be allocated for DTMF receivers. To install single
line sets with CO/PBX line access, CPU circuits must be allocated for dial tone detection.
