Section 2: Components
34 Product Description
Aspire Trunk PCBs
4 CO Loop Start Trunk Card (4COIU-LS1) — P/N 0891005
There are two different types of the COIU PCB. One providing ground start trunks - the other is for
loop start trunks only.
The 4COIU-LS1 PCB provides:
● 4 analog loop start line/trunk circuits - no ground start is provided
● 4 trunk status LEDs
● 4 Caller ID Circuits
● 2 Power Failure Transfer Circuits
● 1 PCB status LED
● 1 run/block switch
The CN3 connector provides connection to 4 analog trunk ports, which are polarity sensitive (tip to
tip, ring to ring). The power failure circuits, however, are not polarity sensitive. A maximum of 15
4COIU-LS1 PCBs per system is allowed, each PCB consuming 4 ports.
8 CO Loop Start Trunk Card (8COIU-LS1) — P/N 0891004
The 8COIU-LSI provides the same features as the 4COIU-LS1 except for the following changes:
The 8COIU-LS1 PCB provides:
● 8 analog loop start line/trunk circuits - no ground start is provided
● 8 trunk status LEDs
● 8 Caller ID Circuits
● 2 Power Failure Transfer Circuits
● 1 PCB status LED
● 1 run/block switch
The CN3 and CN5 connectors each provide connection to 4 analog trunk ports, which are polarity
sensitive (tip to tip, ring to ring). The power failure circuits, however, are not polarity sensitive. A
maximum of 15 8COIU-LS1 PCBs per system is allowed, each PCB consuming 8 ports.
