Section 4: SpeciÞcations and Parts List
Product Description 223
4
Aspire M/L Electrical SpeciÞcations
Power Supply
AC Power Supply
Dedicated 15 Amp circuit
Power Requirements: 120 VAC @ 15A Main Cabinet
Power Consumption: Base Cabinet=360W (493 VA), Expansion Cabinet=360W (493 VA), total
720W (986 VA)
Input Voltage: 85VAC to 135VAC
Frequency: 47 Hz - 63Hz (Rated frequency: 50/60 Hz)
Phase and Wire: Single, 2-Wire
Grounding Requirements: No. 14 AWG copper wire
W
ith input voltage of 120 VAC and with full load conditions:
Output Power: One Power Supply: Base Cabinet=100.5W
Two Power Supplies: Base Cabinet=200.9W, Expansion Cabinet=200.9,
total 401.8W
AC Input I: One Power Supply: Base Cabinet=2.06A
Two Power Supplies: Base Cabinet=4.11A, Expansion Cabinet=4.11A,
total 8.22A
VA @ 120V: One Power Supply: Base Cabinet=246.6VA
Two Power Supplies: Base Cabinet=493.2 VA, Expansion Cabinet=493.2 VA,
total 986.4 VA
KWh @ AC Input I x 120V/1000: One Power Supply: Base Cabinet=0.247 KWh
Two Power Supplies: Base Cabinet=0.493 KWh, Expansion Cabinet=0.493 KWh,
total 0.986 KWh
BTU (KWh x 3413): One Power Supply: Base Cabinet=842 btu
Two Power Supplies: Base Cabinet=1683 btu, Expansion Cabinet=1683 btu,
total 3366 btu
Caution
Double Pole/Neutral Fusing
(power supply fuses located at both the L and N side)
Output Voltage Types +3.42VDC (-3%, +1%) +5VDC (+/- 2%) -48VDC (+/- 5%)
Output Current 1 0.0A - 6.0A 0.0A - 5.0A 0.0A - 1.0A
Output Current 2 0.0A - 3.2A 0.0A - 1.0A 0.0A - 2.0A
Ripple/Noise 50mV p-p 100mV p-p 200mV p-p
Overvoltage Protection 3.7 - 8.0V 5.6 - 13.0V -55.0 - 64.8V
Overcurrent Protection 6.6 - 7.7A 5.5 - 6.5A 2.2 - 2.6A
