Section 4: SpeciÞcations and Parts List
Product Description 237
4
CPU to PC: Serial cross cable 49.21 (15 meters) D-Sub 9-Pin Female
(PC) to D-Sub 9-Pin
Male (CPU)
4-wire LAN (UTP) cable
with category 3 or higher
for 10Base-T, and cate-
gory 5 or higher for 100
Base-TX
Ethernet cross cable
328.08 (100 meters)
CPU to Switching Hub: 4-wire LAN (UTP) cable
with category 3 or higher
for 10Base-T, and cate-
gory 5 or higher for 100
Base-TX
Ethernet straight cable
328.08 (100 meters)
CPU to Printer: Serial cross cable 49.21 (15 meters) D-Sub 9-Pin Female
(Printer) to D-Sub
9-Pin Male (CPU)
IP Telephone LAN (UTP) cable with
category 3 or higher for
10Base-T, and category 5
or higher for 100 Base-TX
328.08 (100 meters) Regardless of
whether it receives
power from the AC
adapter or switch-
ing hub.
VOIPU PCB to IP
Telephone
Standard Ethernet Cable
(cross cable)
328 (100 meters)
VOIPU PCB to Router Standard Ethernet Cable
(straight cable)
328 (100 meters)
PSA Adapter ICT 2-wire 4,547 (1,386 meters) Includes DC resis-
tance of outside line
- excludes internal
resistance of IP tele-
phone
ENTU PCB to PC Standard Ethernet Cable
(cross-cable)
328 (100 meters)
ENTU to Switching Hub Standard Ethernet Cable
(straight-cable)
328 (100 meters)
DID Trunks: ICT 2-wire 24 AWG
Loop resistance (DP only)
9842 ohm @35mA
500 ohm @20 mA
20,997 (6400 meters) Includes SLT or
exchange
Includes resistance
of telephone
2BRIU to ISDN
Terminals:
ICT 4-wire 24 AWG 328 (100 meters) with
Point-Multipoint short
connection
984 (300 meters)300m
with Point-Multipoint
long connection
1,640 (500 meters) with
Point-Point connection
Aspire S Cable Requirements
Device Cable Type Cable Run Length (ft) Notes
