Specifications
142 ◆ Specifications and Parts DSX Product Description
Mechanical Specifications
Equipment Width Depth Height Weight
4 Slot KSU:
8 Slot KSU
10 3/4”
19 1/2”
5 7/8”
5 7/8”
13 11/16”
13 11/16”
4 lbs 5 oz
6 lbs 12 oz
Display Keyset: 7 5/8” 9 1/2” 4 3/4” 2 lb. 5.7 oz.
Super Display Keyset: 7 5/8” 9 1/2” 4 3/4” 2 lb. 5.7 oz.
60-Button DSS Console 5 5/8” 9 1/2” 4 3/4” 1 lb. 3.4 oz.
BGM/MOH Music Source Inputs
Music inputs are located on the CPU Card.
Input Impedance: 10K Ohms
Input Level: +18 dBr (+ 2 dBr) @ 1.0 Khz
USB and Ethernet Specifications
USB and ethernet connectors are located on the CPU Card.
USB: USB 2.0 full speed (12 Mbits/sec)
Ethernet Auto Sensing
2PGDAD Module Specifications
Relay Contacts
Configuration: Normally open
Maximum Contact Ratings: 500 mA @ 24 VDC
250 mA @ 120 VAC
