NEC PE455UL - Page 111

5. Making Connections
91
3. InsertthewirelessLANunitintotheUSB
(wireless LAN) port with the side containing
the indicator facing up.
• SlowlyslidethewirelessLANunitleftand
right, up and down, checking the insertion
slot as you push the unit in.
NOTE:
• DonotforcetoinserttheUSBWirelessLANUnit.
WIRE LESS
WIRE LESS
4. MountthewirelessLANcover.
(1) Insert the hook on the back of the cover
into the groove in the projector and close
the wireless LAN cover.
Hook
Groove
(2) Turn the screw clockwise to tighten it.
* To remove the USB Wireless LAN Unit, dis-
connect the power cord and use the above
procedure.
