6. Installation and Connections
Connecting Component Input
• Selectthesourcenameforitsappropriateinputconnectorafterturningontheprojector.
Inputconnector
SOURCEbuttonontheprojector
cabinet
Buttonontheremotecontrol
COMPUTER1IN COMPUTER1 COMPUTER1
COMPUTER2IN COMPUTER2 COMPUTER2
COMPUTER3IN
COMPUTER3
COMPUTER3
NOTE:
• Normallythecomputersignalandcomponentsignalareidentiedandswitchedautomatically.Ifthesignalcannotbeidentied,
however,selectthesignalat[ADJUST]→[VIDEO]→[SIGNALTYPE]ontheprojector’son-screenmenu.Select“COMPUTER”or
“VIDEO”fortheComputer3videoinputconnectorat[SETUP]→[OPTION(1)]→[SIGNALSELECT(COMP3)](→ page 127).
• ToconnecttoavideodevicewithaDconnector,usethesoldseparatelyDconnectorconverteradapter(modelADP-DT1E).
15-pin - to - RCA (female) × 3 cable adapter
(ADP-CV1E)
BNC (male) to RCA (female)
adapter (not supplied)
Component video RCA × 3 cable (not supplied)
DVD player
Audio Equipment
