2. Projecting an Image (Basic Operation)
Adjusting the vertical position of a projected image (Lens shift)
CAUTION
• Performtheadjustmentfrombehindorfromthesideoftheprojector.Adjustingfrom
thefrontcouldexposeyoureyestostronglightwhichcouldinjurethem.
• Keephandsawayfromthelensmountingportionwhilethelensshiftisinoperation.
Failuretodosocouldresultinhandsbeingpinchedbythemovinglens.
NOTE:
• ThelensshiftfunctionisnotavailableontheprojectorwithNP16FL(PX750U)andNP06FL(PX700W/PX800X)lensinstalled.
 Returnthelensshiftpositiontothehomepositionbeforeinstallingthelenstotheprojector.
• Shiftingthelenstothemaximumintwodirectionscombinedwillcausetheedgesoftheimagetobecomedarkorwillcause
some shadows.
Adjusting with buttons on the cabinet
1. PressoneoftheLENSSHIFT▼▲◀▶buttons.
2. UsetheLENSSHIFT▼▲◀▶buttonstomovetheprojectedimage.
Returningthelensshiftpositiontothehomeposition
PressandholdtheSHUTTER/HOMEPOSITIONbuttonfor2secondstoreturnthelensshiftpositiontothehome
position(nearlycenterposition)
