2. Projecting an Image (Basic Operation)
Adjusting the Tilt Feet
• Turn the left and right tilt feet on the right, left, and rear to
adjust.
 Thetiltfeetlengthenandshortenwhenturned.
 Theheightoftheprojectedimageisadjustedbyturningtheleft
andrighttiltfeet.
 Iftheprojectedimageistilted,turnoneofthetiltfeettoadjust
theimagesothatitislevel.
- Iftheprojectedimageisdistorted,see“2-6CorrectingKeystone
Distortion” (→ page 26).
- The tilt feet can be used to tilt +/− 50 mm/1.97" (6.75°), −9 mm/0.35"
(1.2°).
CAUTION
Therearventsoftheprojectormaybecomeheatedduringnormal
projectoroperation.
Usecautionwhenadjustingthetiltfootontherearside.
NOTE:
• Donotlengthenthetiltfeetontherightandleftanymorethan50mm/1.97"
andthetiltfootontherearanymorethan9mm/0.35"ontherear.Theforce
of doing so may cause the rear foot to come off, resulting in damage to the
projector.
• Donotuse thetiltfeetforanypurpose otherthanadjustingtheprojector’s
projection angle.
Handling the tilt feet improperly, such as carrying the projector by grasping the tilt
feet or hooking it onto a wall using the tilt feet, could damage the projector.
Zoom
UsetheZOOM(+)or(−)buttonontheprojectorcabinettozoominorout.
• ThezoomisnotavailableontheseparatelysoldNP16FL(PX750U)andNP06FL(PX700W/PX800X)lens.
Up
Tilt foot
Down
