225
9. Appendix
504 (19.8)
252 (9.9)
150 (5.9) 150 (5.9)
192 (7.6)
220 (8.7)
117.4 (4.62)
109 (4.3)150 (5.9)150 (5.9)
516 (20.3)
Cabinet Dimensions
Lens center
Lens center
Holes for ceiling mount
Unit:mm(inch)
