39
3. Convenient Features
Theadjustablerangesfor3DReformareasfollows:
HORIZONTAL VERTICAL
CORNERSTONE
PX750U:Max.+/−35°approx.
PX700W/PX800X:Max.+/−40°approx.
Max.+/−30°approx.
KEYSTONE
* Thefollowingareconditionsunderwhichthemaximumangleisachieved:
• WhentheNP18ZL(PX750U)andNP08ZL(PX700W/PX800X)lensisused
• Whenthelensshiftissettothecenter
 Whenthelensshiftisusedandyettheimageisnotdisplayedinthecenterofthescreen,theadjustablerange
willbeincreasedordecreased.
• Imageisprojectedinmaximumwidewiththezoom
NOTE:
• Evenwhentheprojectoristurnedon,thelastusedcorrectionvaluesareapplied.
• IftheCornerstonescreenisunavailable(grayed),pressandholdthe3DREFORMbuttonforaminimumof2secondstoreset
thecurrentcorrectiondata.TheCornerstonefunctionbecomesavailable.
• Turningontheprojectorwillresetthepreviouscorrectionsettingvaluesandcorrectdistortionanewiftheprojectionangleis
changed from the last use.
 Iftheprojectionangleisthesameasinthelastuse,thepreviouscorrectionsettingvaluesareretainedinthememory.
• Therangeofkeystonecorrectionisnotthemaximumtiltangleofprojector.
NOTE:Using3DReformcorrectioncancausetheimagetobeslightlyblurredbecausethecorrectionismadeelectronically.
