NEC UX5000 Easy Setup Guide

1 - 10 Chapter 1
Chapter 1 - WL1700 Setup
Copy the following “initial configuration” to the clipboard (Acrobat: Select Text tool + highlight the text + press Ctrl+C).
set dot1x timeout supplicant 3
set dot1x quiet-period 0
set system ip-address 172.16.254.10
set system countrycode US
set service-profile setup-sp ssid-name NEC-setup
set service-profile setup-sp short-retry-count 3
set service-profile setup-sp long-retry-count 3
set service-profile setup-sp auth-fallthru last-resort
set service-profile setup-sp user-idle-timeout 3600
set service-profile setup-sp keep-initial-vlan enable
set service-profile setup-sp cipher-tkip disable
set service-profile setup-sp cipher-ccmp enable
set service-profile setup-sp rsn-ie enable
set service-profile setup-sp psk-phrase SUMIDA786432
set service-profile setup-sp auth-psk enable
set service-profile setup-sp auth-dot1x disable
set service-profile setup-sp load-balancing-exempt enable
set service-profile setup-sp attr vlan-name default
set service-profile sp1 ssid-name NEC-Voice
set service-profile sp1 no-broadcast enable
set service-profile sp1 short-retry-count 3
set service-profile sp1 long-retry-count 3
set service-profile sp1 auth-fallthru last-resort
set service-profile sp1 static-cos enable
set service-profile sp1 cos 7
set service-profile sp1 cac-mode voice-multiline
set service-profile sp1 user-idle-timeout 3600
set service-profile sp1 active-call-idle-timeout 300
set service-profile sp1 keep-initial-vlan enable
set service-profile sp1 cipher-tkip disable
set service-profile sp1 cipher-ccmp enable
set service-profile sp1 rsn-ie enable
set service-profile sp1 psk-phrase 0246802197531
set service-profile sp1 auth-psk enable
set service-profile sp1 auth-dot1x disable
set service-profile sp1 load-balancing-exempt enable
set service-profile sp1 cac-bw-call 1229
set service-profile sp1 transmit-rate 11g mandatory 18.0,24.0 disabled 1.0,2.0,5.5,6.0,9.0,11.0,12.0,36.0,48.0,54.0
set service-profile sp1 attr vlan-name default
set service-profile sp2 ssid-name NEC-Data
set service-profile sp2 short-retry-count 3
set service-profile sp2 long-retry-count 3
set service-profile sp2 auth-fallthru last-resort
set service-profile sp2 user-idle-timeout 3600
set service-profile sp2 keep-initial-vlan enable
set service-profile sp2 cipher-tkip disable
set service-profile sp2 cipher-ccmp enable
set service-profile sp2 rsn-ie enable
set service-profile sp2 psk-phrase 0246802197531
set service-profile sp2 auth-psk enable
set service-profile sp2 auth-dot1x disable
set service-profile sp2 load-balancing-exempt enable
set service-profile sp2 attr vlan-name default
set enablepass password b6b706525e1814394621eeb2a1c4d5803fcf
set user nec password encrypted 082f494d
set radio-profile rp1 dtim-interval 5
set radio-profile rp1 auto-tune channel-config disable
set radio-profile rp1 active-scan disable
set radio-profile rp1 qos-mode voice-extension
set radio-profile rp1 max-voip-bw 1229
set radio-profile rp1 service-profile sp1
set radio-profile rp1 service-profile sp2
set radio-profile rp1 service-profile setup-sp
set radio-profile default active-scan disable
set ap auto mode disable
set ap 1 serial-id h3tzf0017 model WL1700-MS(AP)
set ap 1 radio 1 channel 1 tx-power 13 radio-profile rp1 mode enable
set ap 2 serial-id h2tzub0301 model WL1500-AP-A
set ap 2 radio 1 channel 6 tx-power 10 radio-profile rp1 mode enable
set ap 3 serial-id h3tzub1036 model WL1500-AP-A
set ap 3 radio 1 channel 11 tx-power 10 radio-profile rp1 mode enable
set ap 4 serial-id h2tzub1527 model WL1500-AP-A
set ap 4 radio 1 channel 1 tx-power 10 radio-profile rp1 mode enable
set ip telnet server enable
set load-balancing mode disable
set vlan 1 port 1
set interface 1 ip 172.16.254.10 255.255.0.0
set ip route default 172.16.254.1 0
Define the circled items
to the customer’s
site requirements.
