Introducing the NEC Versa 1-15
Around the Bottom of the System
The bottom of the NEC Versa offers the features shown next.
Descriptions of the features follow the figure.
Bottom features
A - Coin Screw B - Memory Expansion Bay Cover C - Battery Bay Release
D - Battery E - VersaBay III Device F - VersaBay Release Latches
Memory Expansion Bay Cover — Opens with a coin screw to access
two RAM expansion sockets for small outline double inline memory
modules.
Battery — Contains the system's main battery and is part of the
exterior of the notebook. It is a nine-cell, Lithium-Ion (Li-Ion) battery
with built in battery gauge.
NEC VersaBay III Release Latches — Allows you to remove the
option currently installed in the VersaBay III.
